8K60 DP Input 4K60 HDMI Output Video Wall Controller with RS232 IR Control for Exhibition Hall

Product Categories
Shenzhen Bitvisus Technology Limited
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

8K60 DP Input 4K60 HDMI Output Video Wall Controller with RS232 IR Control for Exhibition Hall

Brand Name : Bitvisus

Model Number : BIT-MSE-8K60D-104Pro

Certification : CE,HDMI,HDCP,RoHS,FCC

Place of Origin : China

MOQ : 1

Price : Contact us！

Payment Terms : T/T,PayPal

Supply Ability : 1000

Delivery Time : 5-8 days

Packaging Details : 36*24*9CM

Prduct Name : BIT-MSE-8K60D-104Pro

Input lnterface : 1*DP 2.1(Copper wire≤3Meters)

Input Maximum Resolution : 2*2:7680*4800P60,7680*4320P60

Output Interface : 4*HDMI2.0(Copper wire≤5Meters)

Output Resolution : 3840*2400P60,3840*2160P60 3840*2400P50,3840*2160P50

Input/Output Color Format : RGB444

Power Supply : 12V5A

Packaging Dimensions : 350mm*240mm*80 mm

Package Weight : 1.3 KG

After-sales Service : 1 years

Contact Now

8K60 DP Input 4K60 HDMI Output Video Wall Controller
The BIT-MSE-8K60D-104Pro is an 8K60 multi-screen extender independently developed by Bitvisus. This industrial-grade high-performance product is specially designed for multi-desktop operation and multi-channel image processing display requirements. The controller supports 1-channel DP interface for 8K60 input and 4-channel HDMI interfaces for 4K60 output, with backward compatibility for conventional resolutions. Whether connecting to 4K large-screen projectors or high-definition displays, it delivers stable, clear, and smooth image output.
8K60 DP Input 4K60 HDMI Output Video Wall Controller with RS232 IR Control for Exhibition Hall
Key Features
  • 1-channel DP interface supporting 8K60 input for clear images with rich detail
  • 4-channel HDMI ports supporting 4K60 output
  • Ultra-high resolution input supporting up to 7680x4800P60/7680x4320P60
  • 2x2 pixel-to-pixel splicing without stretching or distortion for wider field of view
  • EDID management with DIP switch selection, no software operation required
  • Industrial-grade design with thickened 8-layer PCB board and 16KV super anti-static capability
  • Low-power, energy-saving design with overheat protection and anti-interference features
  • Chassis combination design with 2 half-width boxes combined into full-width 1U structure with tray
8K60 DP Input 4K60 HDMI Output Video Wall Controller with RS232 IR Control for Exhibition Hall
Technical Specifications
Product Name BIT-MSE-8K60D-104Pro
Input Interface 1×DP 2.1 (Copper wire ≤ 3 Meters)
HDCP Support HDCP1.4/HDCP 2.3
Input Maximum Pixel Clock Frequency 2400MHz
Input Maximum Resolution 2×2: 7680×4800P60, 7680×4320P60
Input Color Format RGB444
Input Color Depth 8bit
Output Interface 4×HDMI2.0 (Copper wire ≤ 5 Meters)
Output Maximum Pixel Clock Frequency 600MHz
Output Resolution 3840x2400P60, 3840×2160P60, 3840x2400P50, 3840×2160P50
Output Color Format RGB444
Output Color Depth 8bit
Accessory List 1×12V5A power adapter, 8K60 DP cable
8K60 DP Input 4K60 HDMI Output Video Wall Controller with RS232 IR Control for Exhibition Hall
Why Choose Bitvisus?
  • Own warehouse ensuring shipment within 48 hours after payment (weekends and holidays excluded)
  • OEM/ODM services available for custom requirements
  • Extensive product range including Video Wall Controllers, Multiscreen Expanders, Multiviewers, Embedded Projector Fusion systems
  • Proven R&D experience and product quality assurance
Shipping & Payment
Payment Methods: T/T, Visa, PayPal, Western Union, L/C available.
Shipping Options: DHL, UPS, EMS, FedEx, Air freight, Sea freight supported.
